1.Power supply: AC220V/50HZ, 4.0 kw;

2. Pressure: 5.5-6 bar (0.55-0.6 mpa) ;

3. Smart Industrial Camera CCD alignment

4. Adjusting the fitting position of the full-servo manipulator;

5. Automatic loading/receiving of plastic blister products

6. No one is on duty

7. Camera CCD alignment, automatic deviation correction

8. Full-servo manipulator adjusts the fitting position

9. Automatically correct the rotation angle

10. Automatic feeding to the assembler/automatic receiving to the blister

11. Fitting accuracy: ± 0.1 mm

12.Production capacity: 600 pcs/hour

13.Thirteen. Fitting product size: 280 * 170mm

14.Fourteen. Technical Advantages: self-developed robot and vision integration, motion plus control, system customization, convenient for customer adjustment.

15.Suitable for automotive, backlight module industry
